LC-SXG400 LCD Projector
LC-SXG400L (no lens) LCD Projector

Key Features

  • 4,200 ANSI lumens bright with 90% uniformity and a 1300:1 contrast ratio.
  • Native SXGA+ resolution. Compatible with inputs up-to UXGA and WXGA.
  • Supports analog and digital video input in all color standards up-to 1080i.
  • 3 panel LCD imaging delivers a rich, color-saturated picture.
  • 10-bit color processing, for superior color reproduction.
  • Optional wide-angle and telephoto lenses. Instant lens change system.
  • Vertical and horizontal power lens shift and digital vertical keystone correction.
  • Includes most professional input configurations, including 5BNC and DVI-D.
  • Built-in 1 Watt amplifier and speaker system. Closed Caption decoding.
  • Optional network module for projector monitoring and control.
  • Front-accessed, high-capacity air filter simplifies maintenance.
  • Clogged air filter detection with both LED and on-screen warning.
  • Variable power management option. Optional local or remote keylock.
  • Custom warm-up screen option. Built-in color auto picture control.
  • 3 year projector warranty.

Included Accessories: Quick Start Guide, Owner's Manual on CD-ROM, Power Cord, Lens Cover, VGA Computer Input Cable (Dsub15 to Dsub15), Wireless/Wired Remote with Mouse Control (with 2 AAA Batteries), Wired Remote Cable (MiniStereo-MiniStereo), USB Cable for Computer Mouse Control, Serial RS-232 Control Cable (Dsub9-8pinDIN).

Optional Accessories: Replacement Lamp, Soft Carry Bag with Wheels and Telescoping Handle, ATA-Style Shipping Case with Wheels and Telescoping Handle, Wideangle, Midrange and Telephoto Lenses, Ceiling Mount, Ceiling Post & Plate, PjNET Network Interface.

Specifications Overview

(Right click a link and choose "Save ..." to download a file)
(Download a detailed black & white pdf specification sheet)
()



Display Technology 3LCD+One
Brightness (ANSI) 4,200 lumens
Native Resolution SXGA+ (1400x1050)
Max. Computer Input UXGA
Max. Video Input 1080p
Contrast Ratio 1300:1
Panel Size 1.0"
Lens Type (Throw:Width) Supplied without lens
Power Lens Shift U/D 50%; L/R 15%
Keystone Correction U/D 40º
Inputs Dsub15 x 1 or DVI-D (w/HDCP); BNC x 5 or BNC x 3 or BNC x 1 or S-Video x 1; RCA x 1
Outputs Dsub15 x 1;   Variable, Stereo: MiniStereo x 1;
Sound System Mono: 1 Watt; 1.1 in (2.8 cm) x 1 (Mono)
Network Control --
Warranty 3 years
Lamp Life Up to 3,000 hours per lamp
Lamp Part # 610 335 8093
Fan Noise As low as 35 dBA
Air Filter Cartridge (up to 10,000 hours)
Maximum Pitch Up to 360°
Weight 19.6 lb (8.9 kg)
Ceiling Mount Part # --
 NameDescriptionSizeType
Icon of LC-SXG400 Color Data SheetLC-SXG400 Color Data SheetLC-SXG400 Color Data Sheet0.5 MBPDF
Icon of LC-SXG400 Lens ChartLC-SXG400 Lens ChartLC-SXG400 Lens Chart39 KBPDF
Icon of LC-SXG400 Owners ManualLC-SXG400 Owners ManualLC-SXG400 Owners Manual3.9 MBPDF
Icon of LC-SXG400 Pjnet-50 ManualLC-SXG400 Pjnet-50 ManualLC-SXG400 pjnet-50 manual11.6 MBPDF
Icon of LC-SXG400 Remote Control CodesLC-SXG400 Remote Control CodesLC-SXG400 Remote Control Codes9 KBPDF
Icon of LC-SXG400 RS-232 Basic Serial CommandsLC-SXG400 RS-232 Basic Serial CommandsLC-SXG400 RS-232 Basic Serial Commands0.2 MBPDF
Icon of LC-SXG400 RS-232 Extended Serial CommandsLC-SXG400 RS-232 Extended Serial CommandsLC-SXG400 RS-232 Extended Serial Commands0.5 MBPDF
Icon of LC-SXG400 SpecificationsLC-SXG400 SpecificationsLC-SXG400 Specifications95 KBPDF

Related Products

910 330 7184 Filter
Replacement Filter (Base - Foam)
610 335 8093 Lamp
Rated Power: 330W
Lamp type: NSHA
Life Expectancy: 3000h
Lamp Warranty: 6 months / 500h (whichever comes first)(Replaced Pro-Rata)
