C735PS 3LCD Short Throw Laser Projector
7,300 Lumens
4K Enhanced
Laser Light Source
Short Throw Lens
3LCD
C735PS
4K Enhanced Short Throw Laser Projector
7,300 Lumens / 1080p with 4K Enhancement / 3LCD
- 7,300 center lumens bright with 80% uniformity and a 5,000,000:1 contrast ratio.
- 1080p with 4K Enhancement doubles HD video resolution for sharper, more detailed picture.
- Compatible with inputs up-to 1080p, WUXGA and 4K.
- High brightness and contrast with long life 20,000 hour Laser Light Source.
- 10-bit color processing, for superior color reproduction.
- Short-range (1.2:1) manual zoom and focus lens with 0.68-0.82:1 throw ratio.
- Horizontal, Vertical & Corner Keystone Correction.
- Pincushion/Barrel & 6 point Geometric Correction.
- Horizontal & Vertical Manual Lens Shift. Wired network control.
- Compatible with Crestron RoomView™ & AMX Device Discovery Technology.
- Built-in 16 Watt amplifier and speaker system. Closed Caption decoding.
| Brightness | 7,300 lumens |
|---|---|
| Contrast Ratio | 5,000,000:1 |
| Display Technology | 3LCD |
| Panel Size | 0.64″ inorganic |
| Native Resolution | 1080p (1920×1080) with 4K Enhancement |
| Max. Computer Input | 4K (4096×2160) |
| Max. Video Input | 1080p, 4K UHD, 4K DCI |
| Lens Type (Throw:Width) | 0.68-0.82:1 |
| Lens Shift | U/D +50%; L/R +/- 23% |
| Keystone Correction | U/D 30°; L/R 25° |
| Inputs | HDMI x 2; HDBaseT RJ45 x 1; USB-A x 2; |
| Outputs | MiniStereo x 1; S/PDIF x 1 |
| Sound System | 16 Watt amplifier and speaker system |
| Network Control | Wired LAN monitor & control |
Color Data Sheet - C735P, C735PS
1.67 MB pdf
Owner's Manual - C735P, C735PS
43.94 MB pdf
Quick Start Guide - C735P, C735PS
4.62 MB pdf
Remote Control Codes - C735P, C735PS
82.28 KB pdf
RS232 Commands - C735P, C735PS
96.26 KB pdf
CAD Drawing
1.71 MB pdf
Lens Chart
65.02 KB pdf
Specifications
98.04 KB pdfUse the Lens Calculator to calculate the image size and throw distance of a projector and lens combination.
Know the screen size required?
Use the Lens Calculator to find the throw distance, from the front of the projector lens to the screen, required to produce that image size with the available lenses.
Starting with a specific Throw Distance?
The Lens Calculator will show you the screen sizes available from that distance with the projector and lens combinations available.
0173-4293 Universal Ceiling Mount
Universal Projector Ceiling Mount
63340119 Filter
Replacement Filter
C835, C735, C735P/PS
EK-820LU, EK-720LU, EK-700LU,
EK-65LU, EK-55LU
